Horizon

Supercontinuum Fiber Laser with Ultra Flat Spectrum

Spectral Range:

450 – 2300 nm

Average Power:

> 3 W

Visible Range (450-750 nm) Average Power:

≥ 250 mW

Typical Optical Spectrum
Horizon Supercontinuum Ultra Flat Fiber Laser

Ultra Flat Spectrum

Outstanding Power Stability

The Horizon Supercontinuum Fiber Laser is a cutting-edge optical source designed to redefine performance in spectroscopy and imaging. With an ultra-flat spectrum, free of spurious spectral peaks, it spans an impressive spectral range of 450 and 2300 nm.

With its spatial coherence, broad spectral coverage and spectral flatness, Horizon outperforms traditional supercontinuum sources

Ideal for advanced scientific and industrial applications, including fluorescence lifetime imaging and beyond, where consistent, high- quality illumination is critical. Whether in research or industrial environments, Horizon empowers users with a robust, high-performance solution for their optical needs.

Technical Specifications

Spectral Range

450-2300 nm

Repetition Rate

80 MHz

Average Power

> 3 W

Visible Range (450-750 nm) Average Power:

≥ 250 mW

Pulse Duration

< 10 ps @ 1060 nm | < 650 ps full spectrum*

Power Stability

≤ 0,5 % (std. dev.)

Polarization

Unpolarized

Output Port

Single Mode Fiber, 1.0 m length (customizable)

Optical Output

Collimated (in the range 450-1000 nm), Single-mode across full spectrum

Synchronization / Connections

TTL (SMA) ; NIM (SMA) Under request

Beam Diameter @ 1 m of distance

@ 470nm ≤ 2mm/@ 580nm ≤ 2,5mm / @ 725nm ≤ 3,5mm/@ 1150nm ≤ 5,5mm

Spatial Mode Quality (M2 )

< 1,2

Cooling

Thermoelectric cooler + air cooling

Power Requirements

110V - 220V / 50Hz-60Hz

Operating Temperature

20 - 30 ºC

Storage Temperature

0 - 60 ºC

Dimensions

436x560x151 mm (WxDxH)

Control:

Manual / Software via USB

Safety Connections:

Interlock / Key

Optical Spectrum

Typical Optical Spectrum

Security

This product is a Class 4 laser. Appropriate safety measures according to such laser class should be taken in its installation and use SPECTRAL PROFILE AND OTHER DETAILED SPECS UNDER REQUEST

SPECTRAL PROFILE AND OTHER DETAILED SPECS UNDER REQUEST

*Estimated value
